10-2-4. GPI Output Settings
Available GPI output functions are shown below.
Output Setting List
Port No.
Function
When tally signals are supplied
Port
1 - 30
None
No tally output
Follow GPI In Settings
When the input function of the same port is
enabled.
All DC/FAN Alarm
(*1)
When one or more cooling fans or power supply
units in the main unit and FA-10DCCRU fail.
FA-10DCCRU FAN Alarm
When the FA-10DCCRU cooling fan fails.
MU/FA-10DCCRU FAN Alarm
When one or more cooling fans in the main unit
and FA-10DCCRU fail.
MU FAN1 Alarm
When FAN1 in the main unit fails.
MU FAN2 Alarm
When FAN2 in the main unit fails.
MU FAN3 Alarm
(*2)
When FAN3 in the main unit fails.
MU FAN4 Alarm
(*2)
When FAN4 in the main unit fails.
DC Power Alarm
(*3)
When one or more power supply units in the main
unit fail.
DC Power1 Alarm
(*3)
When Power Supply 1 in the main unit fails.
DC Power2 Alarm
(*3)
When Power Supply 2 in the main unit fails.
Reference Input Video Status
When a reference input video is detected in the
main unit.
FS1 Input Video Status
When an input video for FS1 is present in the
main unit.
FS2 Input Video Status
(*4)
When an input video for FS2 is present in the
main unit.
FS3 Input Video Status
(*5)
When an input video for FS3 is present in the
main unit.
FS4 Input Video Status
(*5)
When an input video for FS4 is present in the
main unit.
FS5 Input Video Status
(*5)
When an input video for FS5 is present in the
main unit.
FS6 Input Video Status
(*2)
When an input video for FS6 is present in the
main unit.
FS7 Input Video Status
(*2)
When an input video for FS7 is present in the
main unit.
FS8 Input Video Status
(*2)
When an input video for FS8 is present in the
main unit.
FS9 Input Video Status
(*2)
When an input video for FS9 is present in the
main unit.
FS10 Input Video Status
(*2)
When an input video for FS10 is present in the
main unit.
(*1) The system detects DC power alarm/s, as needed, for the second power supply in the main unit.
(*2) Used for FA-1010 connection.
(*3) Used for main units with redundant power supplies
(*4) Used for FA-505, FA-1010 or FA-9520 (in FA-9520 mode) connection
(*5) Used for FA-505 or FA-1010 connection
