6-11. Verifying Settings
Repeatedly pressing the + (or - ) button displays settings one after another.
Settings are not be displayed while FS SEL is lit.
6-11-1. When in Color Correction Mode
When in BALANCE or DIFFERENTIAL Correction Mode, repeatedly pressing the + button
displays settings one after another in the following order.
Video Level→Y Level→C Level→Setup/Black→Hue→
White R Level→White G Level→White B Level→
Black R Level→Black G Level→Black B Level→
Gamma R Level→Gamma G Level→Gamma B Level
* Pressing the - button displays settings in the reverse order.
When in SEPIA Correction Mode, repeatedly pressing the + button displays settings one
after another in the following order.
Video Level→Y Level→Sepia Level→Setup/Black→Sepia Color→Gamma G Level
* Pressing the - button displays settings in the reverse order.
6-11-2. When in Clip Mode
6-11-2-1. RGB Clip
With the RGB Clip menu displayed, pressing + (and with FS SEL unlit) displays the
following settings.
(When FA-505 Soft Version is 2.00 or later)
RGB White Clip→RGB Black Clip→White Knee Point→White Knee Slope
→Black Knee Pont→Black Knee Slope
(When FA-505 Soft Version is 1.21 or earlier)
RGB White Clip→RGB Black Clip
* Pressing the - button displays settings in the reverse order.
6-11-2-2. YPbPr Clip
With the YPbPr Clip menu displayed, pressing + (and with FS SEL unlit) displays
settings in the following order.
Y White Clip→Chroma Clip→Y Black Clip
* Pressing the - button displays settings in the reverse order.
