Redwood Global Ltd - ST6P
Operator and Maintenance Manual
Chapter 1: Machine Overview
1.11 IGNITION SWITCH
Figure 13 - Ignition switch
Off position (1, Figure 13)
This is the normal position when the machine is not in use.
On position (2, Figure 13)
This is the normal operating position. All electrical systems are on.
Start position (3, Figure 13)
This is the position for starting the engine. The key should be released from this position
as soon as the engine starts.
12-00-001 v4.0 30
