5.9 CHANGING THE BLADES
WARNING
The blades must not be used beyond the wear mark. Failure to comply with this
could result in damaging the machine, injury, or loss of life.
WARNING
When changing the blades, be extremely careful of sharp edges.
WARNING
Rigger gloves must be worn whilst changing the blades. Hold the blades by the
flat end.
WARNING
When moving the flywheel in any direction, position your hands correctly to
avoid injury. Position your hands as shown below:
Figure 49 - Pushing the flywheel away
from you
Figure 50 - Pulling the flywheel towards
you
CAUTION
Failure to keep blades sharp will overload the engine and bearings which could
result in a machine breakdown.
1. Stop the engine.
2. Remove the key from the ignition and keep in a safe place.
3. Disconnect the battery leads.
4. Open the bonnet.
Chapter 5: Maintenance
Redwood Global Ltd - ST6P
Operator and Maintenance Manual
83 12-00-001 v4.0
