FORST ST6P - Starting the Machine; Figure 30 - Maximum Throttle Position; Figure 31 - Key in the on Position

4.3 STARTING THE MACHINE
Carry out daily checks before first use of machine everyday.
To start safely, follow the start up procedure below.
1. Insert the key into the ignition.
2. Make sure that the discharge chute is pointing in a safe direction.
3. Push the throttle level fully down to the maximum throttle position.
Figure 30 - Maximum throttle position
4. Turn the key 90° clockwise.
The screen switches on.
Figure 31 - Key in the ON position
5. After the screen has switched on, turn the key 45° clockwise. Hold the key in this
position until the engine starts or the crank cycle finishes. The crank cycle
typically takes 5seconds.

Chapter 4: Operation
Redwood Global Ltd - ST6P
Operator and Maintenance Manual
61 12-00-001 v4.0
