Redwood Global Ltd - ST6P
Operator and Maintenance Manual
Chapter 4: Operation
Check the feed rollers:
8. Open the bonnet.
9. Open the chipping chamber cover.
10. Using a suitable tool, loosen the 4x nuts located on top of the 2x spring hangers.
Figure 40 - Spring hanger
11. Release the feed roller spring tension on both sides. Remove the spring if
necessary.
12. Put the top feed roller lifting tool (2, Figure 41) into the slot (3, Figure 41).
Figure 41 - Feed roller spring tension
12-00-001 v4.0 68
