5.8 REMOVING THE PANEL
Removing the panel will give you access to the following:
l
Battery
l
Stone trap
l
Fuses
l
Spring
To remove the side panel:
1. Stop the engine.
2. Remove the key from the ignition and keep in a safe place.
3. Remove the bolts securing the panel (2,Figure 47).
4. Remove the side panel (1, Figure 48).
Figure 47 - Remove bolts
Chapter 5: Maintenance
Redwood Global Ltd - ST6P
Operator and Maintenance Manual
81 12-00-001 v4.0
