Redwood Global Ltd - ST6P
Operator and Maintenance Manual
Chapter 4: Operation
Figure 32 - Key in the engine crank position
• If the engine doesn't fire, turn the key to the OFF position and return to step
4
• If the engine doesn't fire after trying three times, check for faults.
►
For more information, refer to "Troubleshooting" on page 109
6. Once engine has started, allow the engine to idle for 30 seconds for the oil to
flow around the engine before slowly increasing the speed to maximum.
NOTICE
Increase and decrease the engine speed slowly, especially during the first 50
hours of operation.
Figure 33 - Throttle in idle position
7. Check the safety system is functioning correctly.
8. The machine is now ready for use. Wait until the engine is warm before heavy
use.
12-00-001 v4.0 62
