5.14 CHANGING THE HYDRAULIC FILTER
CAUTION
Use suitable protective gloves to prevent fluid contact with skin.
CAUTION
Use approved local authority environmental procedures when disposing of
fluids and filters.
1. Turn off the engine.
2. Remove the ignition key and keep it in a safe place.
3. Lift the bonnet and locate the hydraulic filter housing.
Figure 68 - Cap on the hydraulic filter housing
4. Using a suitable tool, unscrew and remove the cap from the hydraulic filter
housing.
5. Locate the lifting tab on top of the hydraulic filter and gently lift the tab by a
small amount.
This allows the oil on top of the filter to leak back into the tank.
Figure 69 - Lifting tab
6. When the oil level has dropped, remove the filter and the filter bowl together.
7. Remove the filter from the filter bowl.
8. Dispose of the filter.
9. Clean the filter bowl.
Chapter 5: Maintenance
Redwood Global Ltd - ST6P
Operator and Maintenance Manual
95 12-00-001 v4.0
