Machine Components
43
Product Overview
2
5 Lower center tray (Output
tray)
Copies and prints are delivered here, facing down.
6 Power switch Switches the power of the machine on and off.
Refer to "Power Source" (P.51).
7 Front cover Open this cover to replace the consumables.
8 Tray 1, 2, 3, 4 Load paper here.
Note •Trays 3 and 4 are optional for some models.
• The Envelope Tray (optional) can be inserted into the slot for Tray 1. The
standard Tray 1 cannot be used when the Envelope Tray is used.
9 Locking casters Used for locking the wheels of the machine. Lock these casters after moving
the machine to its installation site.
10 Tray 5 (Bypass) Used for loading non-standard paper, such as thick-stock paper and other
special media, that cannot be loaded in Trays 1 to 4.
11 Side Tray (optional) Copies and prints are delivered here, facing up.
12 Stylus pen holder Stores the stylus pen.
13 Stylus pen Used for touching the touch screen on the control panel to configure
settings.
Note •You can directly touch the touch screen not only with the stylus pen but
also with a finger.
14 Stand (optional) The machine with Trays 1 and 2 can be mounted on this Stand.
The attached casters also allows you to move the machine.
Note •The stand may not be available for some models.
No. Component Function
