84 Printing Basics
Loading Print Media
Loading print media properly helps prevent jams and ensures trouble-free printing.
Before loading print media, identify the recommended print side of the print media. This information is usually on the
print media package.
NOTE:
• After loading paper in the feeder, specify the same paper type on the operator panel.
Capacity
The MPF can hold:
• 150 sheets of standard paper
• 16.2 mm (0.64 inches) of thick paper
• One sheet of coated paper
• Five envelopes
• 16.2 mm (0.64 inches) of labels
The PSI can hold:
• 10 sheets of standard paper or one sheet of other paper
Print Media Dimensions
The MPF accepts print media within the following dimensions:
• Width: 76.2 – 215.9 mm (3.00 – 8.50 inches)
• Length: 127 – 355.6 mm (5.00 – 14.00 inches)
The PSI accepts print media within the following dimensions:
• Width: 76.2 – 215.9 mm (3.00 – 8.50 inches)
• Length: 190.5 – 355.6 mm (7.50 – 14.00 inches)
