8.5 Replication Wizard
8.5 Replication Wizard
The Replication wizard provides guided assistance for configuring the ETERNUS CS800 to
send replicated data to another ETERNUS CS800 system as part of disaster recovery plan.
The wizard can also help you configure the ETERNUS CS800 to receive replicated data from
another ETERNUS CS800 system.
Sources send replicated data, and targets receive replicated data. A target system can
receive data from up to 10 sources.
A source system can send data to up to two targets. Finally, one system can act as both a
source and a target.
Additional Information
l For more information about working with data replication, see "Replication" on page
340.
l Use the Replication wizard (or the Configuration > Replication page) to configure
other ETERNUS CS800 systems that this ETERNUS CS800 is configured to send replicated
data to or receive replicated data from. You should configure a target system before
configuring source systems.
To begin the Replication wizard, on the Wizards menu, click Replication.
Step 1: About
1. Read the information about the wizard.
2. Click Next to continue.
At any time while using the wizard, you can click Previous to return to the
previous step.
Figure 116: Replication Wizard: About
Step 2: System
1. If data on this ETERNUS CS800 will be replicated to another ETERNUS CS800 system,
enter target information under Target (see "Replication Wizard: System" on page
154).
ETERNUS CS800 152

Fujitsu ETERNUS CS800 S6 Specifications

General

Storage drives installed	-
Installed storage drive type	HDD
Total installed storage capacity	- TB
Maximum supported storage capacity	24 TB
Chassis type	Rack (2U)
Certification	CSA-C22.2 No. 60950-1, GOST-R, UL 60950-1, EN 60950-1, IEC 60950-1, CNS 13438, FCC Part-15 Class A, ICES 003 Class A, BSMI Class A, C-Tick, AS/NZ CISPR 22 Class A, EN 55022 Class A, VCCI Class A
Product color	Black
Sustainability certificates	RoHS
RJ-45 ports quantity	1
Remote management port	RJ-45 (Gigabit)
AC input voltage	200-240 V
AC input frequency	50 - 60 Hz
Power supply unit (PSU) capacity	290 W
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Software support	Atempo (Time Navigator), Commvault Software, Computer Associates (BrightStor ARCserve Backup), EMC (NetWorker), HP (DataProtector), IBM (Tivoli Storage Manager), Quest (NetVault, vRanger), Veritas (Backup Exec, NetBackup), Veeam (Backup & Replication)

Weight and Dimensions

Depth	770 mm
Width	482.6 mm
Height	88.9 mm
Weight	25000 g
