Fujitsu ETERNUS CS800 S6 User Manual

12.5 VTL Status
Category Description
Deduplicated Partitions (ETERNUS CS800 VTL and Multi-Protocol configurations
only) The amount of data stored in deduplicated
partitions. This includes incoming data from Cartridge
Based Replication, and incoming data from Failback
replication.
OST Storage Servers (ETERNUS CS800 NAS and Multi-Protocol configurations
only) The amount of data stored in deduplicated
OpenStorage (OST) storage servers. This includes
incoming data for OST and ETERNUS CS800 Accent.
Data After Reduction
The Data After Reduction value represents the final, reduced size of all data that has been
processed by the data deduplication and compression engines.
Data after reduction is divided into the following categories:
Category Description
Total Reduction Ratio The total reduction ratio of all data that has been
processed by the data deduplication and compression
engines (Data Before Reduction divided by Data After
Reduction).
Deduplication Ratio The deduplication ratio of all data that has been
processed by the data deduplication engine.
Compression Ratio The compression ratio of all data that has been processed
by the compression engine.
12.5 VTL Status
The VTL Status page allows you to view information about virtual tape library (VTL)
components, including tape drives, storage slots, and cartridges. You can view a physical
or logical representation of VTL components, or view VTL performance statistics.
For information about creating VTLs, see "Adding a VTL Partition" on page 206.
To access the VTL Status page, click the Status menu, and then click the VTL tab.
The VTL Status page contains the following tabs:
l "Physical View" on page 397
l "Logical View" on page 398
l "Performance View" on page 399
ETERNUS CS800 396

Fujitsu ETERNUS CS800 S6 Specifications

General

Storage drives installed	-
Installed storage drive type	HDD
Total installed storage capacity	- TB
Maximum supported storage capacity	24 TB
Chassis type	Rack (2U)
Certification	CSA-C22.2 No. 60950-1, GOST-R, UL 60950-1, EN 60950-1, IEC 60950-1, CNS 13438, FCC Part-15 Class A, ICES 003 Class A, BSMI Class A, C-Tick, AS/NZ CISPR 22 Class A, EN 55022 Class A, VCCI Class A
Product color	Black
Sustainability certificates	RoHS
RJ-45 ports quantity	1
Remote management port	RJ-45 (Gigabit)
AC input voltage	200-240 V
AC input frequency	50 - 60 Hz
Power supply unit (PSU) capacity	290 W
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Software support	Atempo (Time Navigator), Commvault Software, Computer Associates (BrightStor ARCserve Backup), EMC (NetWorker), HP (DataProtector), IBM (Tivoli Storage Manager), Quest (NetVault, vRanger), Veritas (Backup Exec, NetBackup), Veeam (Backup & Replication)

Weight and Dimensions

Depth	770 mm
Width	482.6 mm
Height	88.9 mm
Weight	25000 g
