Fujitsu ETERNUS CS800 S6 User Manual

1 Introduction
1.1 Preface
This manual introduces the FUJITSU Storage ETERNUS CS800 enhanced data protection
system and provides information about:
l Features and hardware
l Installation
l System operations
l Configuration
l Web interface
l Basic troubleshooting
l Basic spare parts replacement procedures
This manual applies to the ETERNUS CS800 V3.2.7 software which supports the
ETERNUS CS800 S6 hardware. For hardware related topics for an ETERNUS CS800
S2/S3/S4/S5 system, please continue to use the appropriate manual.
Audience
This manual is written for ETERNUS CS800 system operators and system administrators.
It is useful for the audience to have a basic understanding of Linux.
Document organization
Following is a brief description of chapter contents.
l Chapter "Important Information" on page 14 provides essential information regarding
safety when working on your ETERNUS CS800.
l Chapter "System Description" on page 24 provides an overview of the ETERNUS CS800
system.
l Chapter "Hardware Description" on page 39 describes the hardware components of the
ETERNUS CS800 system and instructions for turning on/off the system.
l Chapters "Rack Requirements" on page 74 , "Installing the ETERNUS CS800 S6 Modules"
on page 76 and chapter "Initial Configuration, Connecting with the Network" on page
99 describe all steps to install the hardware for the ETERNUS CS800 S6 system and the
initial software configuration.
ETERNUS CS800 9

Fujitsu ETERNUS CS800 S6 Specifications

General

Storage drives installed	-
Installed storage drive type	HDD
Total installed storage capacity	- TB
Maximum supported storage capacity	24 TB
Chassis type	Rack (2U)
Certification	CSA-C22.2 No. 60950-1, GOST-R, UL 60950-1, EN 60950-1, IEC 60950-1, CNS 13438, FCC Part-15 Class A, ICES 003 Class A, BSMI Class A, C-Tick, AS/NZ CISPR 22 Class A, EN 55022 Class A, VCCI Class A
Product color	Black
Sustainability certificates	RoHS
RJ-45 ports quantity	1
Remote management port	RJ-45 (Gigabit)
AC input voltage	200-240 V
AC input frequency	50 - 60 Hz
Power supply unit (PSU) capacity	290 W
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Software support	Atempo (Time Navigator), Commvault Software, Computer Associates (BrightStor ARCserve Backup), EMC (NetWorker), HP (DataProtector), IBM (Tivoli Storage Manager), Quest (NetVault, vRanger), Veritas (Backup Exec, NetBackup), Veeam (Backup & Replication)

Weight and Dimensions

Depth	770 mm
Width	482.6 mm
Height	88.9 mm
Weight	25000 g
