A supplementary procedure describing how to install the separator roller on the scanner is provided below.
a Insert the right side of the separator roller shaft first, then the left side so that the tab fits in the
groove.
b Push up the lever which is located on the left side of the separator roller.
c Push up the lever which is located on the right side of the separator roller.
d Close the roller cover, and make sure that both ends of the cover are locked firmly.
6 Close the ADF.
For details, refer to How to Close the ADF (page 28).
Be careful not to get your fingers caught when closing the ADF.
ATTENTION
● Do not close the ADF while the roller cover is open.
● Confirm that the separator roller is installed properly. When the separator roller is not installed properly,
it causes feeding errors such as paper jams.
7 Plug in the power cable and turn on the scanner.
For details, refer to How to Turn the Power ON (page 19).
8 Reset the separator roller counter.
Use one of the following methods to reset the counter.
● Select [23: Show/Clear Counters] from [Main Menu] on the operator panel, then reset the counter.
For details, refer to Checking and Resetting the Counters (page 83).
● Start up the Software Operation Panel and reset the counter.
For details, refer to Resetting the Sheet Counters (page 218).
Replacing the Consumables
146
