Selected range = Disable, Start = 0 mm, End = 0 mm
Multifeed is detected only for the areas in light pink.
HINT
When detecting the overlapping of documents, the multifeed detection rate may drop if the documents
are glued tightly or attached together by static electricity.
Example 3: (Bad example)
Setting details are as follows.
● Specified position: Left
Selected range = Disable, Start = 310 mm, End = 400 mm
● Specified position: Middle
Selected range = Enable, Start = 320 mm, End = 450 mm
● Specified position: Right
Operational Settings
259
