CHAPTER 3
Small Configuration
Installing the Optical/Tributary Shelf
FNC-7500-0061-200
Issue 1, May 2009
FLASHWAVE 7500 Release 6.1
Equipment Installation
3-44
Fujitsu and Fujitsu Customer Use Only
Figure 3-28 [p. 3-44] shows a right-side view of the Optical/Tributary shelf after the flange is
mounted.
12 Install the Optical/Tributary shelf in the rack. Secure the shelf to the rack using four rack
mounting screws on each side of the shelf.
This procedure is complete.
Figure 3-28: Flange Mounted on Right Side of Optical/Tributary Shelf (23-Inch Rack Installation)
