CHAPTER 5
Extension Configuration
Installing Cables
FNC-7500-0061-200
Issue 1, May 2009
FLASHWAVE 7500 Release 6.1
Equipment Installation
5-48
Fujitsu and Fujitsu Customer Use Only
5.13 Installing Cables
NO.SUBSECTION PAGE
This section includes the following subsections: Section
5.13.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-48
5.13.2 Prerequisites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-48
5.13.3 Extension Shelf Backplane . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-49
5.13.4 Installing Modem Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-50
5.13.5 Installing Housekeeping Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-52
5.13.6 Installing Office Alarm Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-55
5.13.7 Installing OSS Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-57
5.13.1 Overview
The procedures in this section cover the connections made to the Extension shelf backplane of
the FLASHWAVE 7500 Extension Configuration system. Figure 5-22 [p. 5-49] shows the
backplane connectors and connector designations for the Extension shelf.
All fiber cabling and connections to the shelf plug-in units are made during system turn-up.
Refer to System Turn-Up, for fiber cabling information. For a detailed description of
FLASHWAVE 7500 cables and shelf connectors, refer to Cable and Wiring Guide.
Note: Some of the connectors on the Extension shelf backplane may be for future use. However,
this practice defines all connectors on the shelf backplane and applicable cables that may be
used in future releases.
Note: All cabling from the Extension shelf backplane should be connected only to other shelves
and equipment within the same building.
5.13.2 Prerequisites
The tools required for performing the procedures listed in this section are as follows:
■
Cable termination tools
■
Common hand tools
