Without "A.B.S"
With "A.B.S"
Home screen
Menu screen Racing menu screen
A.B.S
A.B.S ON/OFF is indicated on
the home screen for a few sec-
onds.
It is displayed in the home screen.
When the A.B.S is ON.
A.B.S
Cycle speed
Y:
(Brake return time)
B rake
return
Servo travel
Stick operation
Stick point
X: (Brake application time)
88
Function
A.B.S
A.B.S
When the brakes are applied while cornering with a 4-Wheel Drive or
other type of vehicle, understeer may occur. The tendency to under-
steer can be eliminated and corners can be smoothly cleared by using
this function.
- When the brakes are applied, the throttle servo will pulse inter-
mittently. This will have the same effect as pumping the brakes in
a full size car.
- The brake return amount, pulse cycle, and brake duty can be ad-
justed.
- By setting the
"
Brake mixing
"
function (page 104), it can also be
set for 2nd and 3rd (auxiliary channel) brake.
Operation
- Mode : Function ON/OFF
ABS function ON/OFF setting. When
using the ABS function, set to
"
ON
"
.
- Brake return
Sets the rate at which the servo re-
turns versus throttle stick operation
for brake release. When set to 0%, the
ABS function is not performed. When
set to 50%, the servo returns 50% (1/2)
of the throttle stick operation amount
and when set to 100%, the servo re-
turns to the neutral position.
