3
Left side
www.gateway.com
Left side
Component Icon Description
Microphone jack Plug a microphone into this jack.
Line in jack Plug an external audio input source (such as a stereo) to this jack
so you can record sound on your notebook or play sound through
the notebook speakers.
Headphone jack Plug amplified speakers or headphones into this jack. The built-in
speakers are turned off when speakers or headphones are
plugged into this jack.
The headphone jack on the optional port replicator is turned off
when headphones are plugged into this jack.
IEEE 1394 port Plug an IEEE 1394 (also known as Firewire
®
or i.Link
®
) device
(such as a digital camcorder) into this 4-pin IEEE 1394 port. For
more information, see “Connecting a digital video camera” on
page 144.
PC Card
eject
buttons
PC Card
slots
Microphone jack
Headphone jack
Line in jack
IEEE 1394 port
USB ports
