NE-M Installation Guide H5692448
850050111 Issue 03 August 2017 8
Eco Capable Systems - Pulsar Plus only
Eco capable systems (Eco systems) add support for multiple power inputs of multiple types, including PV (photo voltaic
or solar) arrays.
Power Input
• PV (photo voltaic or solar) arrays
• AC generators
• AC mains
Rectifiers
NE Eco Rectifiers
4
• Input - AC or DC (PV or solar) input
• MPPT (Maximum Power Point Tracking) maximizes power harvested from PV arrays
• Recommended for all rectifier positions in Eco systems
Controller
• Pulsar Plus
• Eco features included (PV, Gen Set, etc.)
4
REQUIRED – Eco rectifiers in all DC (PV or solar) powered rectifier positions.
RECOMMENDED – Eco rectifiers in all Eco system rectifier positions.
NOT RECOMMENDED – non-Eco rectifiers in Eco systems.
Non Eco rectifiers will not function properly when powered by DC (PV or solar) input in Eco systems.
Use of non-Eco rectifiers in Eco systems increases the risk of improperly filling all system rectifier positions.
Non Eco rectifiers may be installed in AC powered rectifier positions of Eco systems.
