GE MEDICAL SYSTEMS
DIRECTION 2380207, REVISION 7 LOGIQ™ 5 PRO SERVICE MANUAL
1-14 Section 1-3 - Safety Considerations
1-3-5 Label Locations
NOTE: For the symbols shown in the illustration below, refer to previous pages in this chapter.
1.) Caution for Possible injury : “Never put any device onto the Monitor”
2.) Caution for Hazardous movement : (Inside of the OP rear Cover)
3.) Defibrillator Label ““Do not use with Defibrillator”(On optional ECG Module)
Figure 1-1 OUTSIDE MARKINGS OF LOGIQ™ 5 PRO
(Monitor)
(1)
(2)
(3)
To Next Page
