GE MEDICAL SYSTEMS
DIRECTION 2380207, REVISION 7 LOGIQ™5 PRO SERVICE MANUAL
5-32 Section 5-7 - External I/O (Rear Panel)
5-7-2-3 Cable Connection- VCR
Connect the cables listed below between the Sony VCR and the console.
Figure 5-26 Cable Connection between VCR and Console
RS232C CABLE
S. Video CABLE for VIDEO SIGNAL
(supplied with VCR)
POWER CABLE
REAR PANEL of VIDEO CASSETTE RECORDER
~AC IN
Rear Panel of JUPITER
ON
OFF
AUDIO
IN
CH-1/L
CH-2/R
CH-1/L
CH-2/R
S. VIDEO
S. VIDE O
AUDIO
OUT
MONIT OR
OUT
VID EO
OUT
VID EO IN
INDICATE
ON
OFF
