GE LOGIQ E10 Service Manual

DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
Chapter 6 Service Adjustments 6 - 13
Section 6-4
Operator Panel movement
6-4-1 Purpose of this section
The Operator Panel movement within the LOGIQ E10 is described in this section.
Contents in this section
6-4-1 Purpose of this section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-13
6-4-2 Adjusting the Z-Mechanism . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-14
6-4-3 Adjusting the XY Locking Mechanism . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-15
6-4-4 Using the Park Lock Properly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-16
Adjustment Locations and Manual Releases
Table 6-7 Adjustment Locations and Manual Releases
Items / Corresponding Graphic
Z-Mech Adjustment (A)
XY Locking Mechanism Adjustment (B)
XY Manual Release for Lock and Brake Mechanism and Adjustment (C)

GE LOGIQ E10 Specifications

General

Touchscreen	Yes
3D/4D Imaging	Yes
Applications	Vascular, Cardiac, Musculoskeletal, OB/GYN
Image Storage	USB, Network
Connectivity	DICOM, Ethernet, Wireless
