GE LOGIQ E10 Service Manual

DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
Chapter 8 Replacement Procedures 8 - 399
8-15-2 Assembling or replacing the Roll Stand (cont’d)
5.) Loosen the knob slightly, guide the arm into the channel and move it to the mounting position.
NOTE: Make sure the Transformer Support Platform (larger view) in Figure 8-14 "Loosening Knob" on
page 8-399 is installed in the UP position.
NOTE: The channel fits between the front and rear slide plates.
Figure 8-14 Loosening Knob
Figure 8-15 Channel Location

GE LOGIQ E10 Specifications

General

Touchscreen	Yes
3D/4D Imaging	Yes
Applications	Vascular, Cardiac, Musculoskeletal, OB/GYN
Image Storage	USB, Network
Connectivity	DICOM, Ethernet, Wireless
