DIRECTION 5750007-1EN, REV. 1 LOGIQ E10 BASIC SERVICE MANUAL
2 - 2 Section 2-2 - General LOGIQ E10 requirements
Section 2-2
General LOGIQ E10 requirements
Contents in this section
2-2-1 LOGIQ E10 environmental requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2
2-2-2 Electrical requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4
2-2-3 EMI limitations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-6
2-2-4 Probe environmental requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-8
2-2-5 Time and manpower requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-8
2-2-1 LOGIQ E10 environmental requirements
If the LOGIQ E10 is very cold or hot
When unpacking the LOGIQ E10, allow the temperature to stabilize before powering up.’
Refer to Table 2-1 for guidelines on reaching operational temperatures from storage or transport
temperatures.
Environmental specifications
The LOGIQ E10 should be operated, stored, and transported according to the listed environmental
requirements.
NOTE: Probe environmental specifications may be different than the LOGIQ E10.
Refer to Table 2-2 for environmental specifications
CAUTION
RISK OF DAMAGE TO EQUIPMENT.
IF THE ULTRASOUND SYSTEM IS VERY COLD OR HOT, DO NOT TURN ON ITS POWER UNTIL
IT HAS HAD A CHANCE TO ACCLIMATE TO ITS OPERATING ENVIRONMENT.
Table 2-1 LOGIQ E10 Acclimate Time
o
C
60 55 50 45 40 35 30 25 20 15 10 5 0 -5 -10 -15 -20 -25 -30 -35 -40
o
F
140 131 122 113 104 95 86 77 68 59 50 41 32 23 14 5 -4 -13 -22 -31 -40
Hrs 864200000002468101214161820
Table 2-2 Environmental Specifications for the LOGIQ E10
Operational Storage Transport (< 16 hrs.)
Temperature
10º - 35º C
(50º - 96º F)
-10º - 50º C
(14º - 122º F)
-10º - 50º C
(14º - 122º F)
Humidity
30% - 80%
non-condensing
30% - 80%
non-condensing
30% - 80%
non-condensing
Pressure 70 - 106 kPa 70 - 106 kPa 70 - 106 kPa
Heat Dissipation
3070 Btu/hour n/a n/a

GE LOGIQ E10 Specifications

General

Touchscreen	Yes
3D/4D Imaging	Yes
Applications	Vascular, Cardiac, Musculoskeletal, OB/GYN
Image Storage	USB, Network
Connectivity	DICOM, Ethernet, Wireless
