122 GE INFORMATION D20E ETHERNET I/O MODULE INSTRUCTION MANUAL
APPENDIX A: STANDARDS & PROTECTION
Table 42: Safety publications
Table 43: Environmental standards
IEC 61000-4-6
IEC 60255-22-6
Immunity to conducted disturbances,
induced by radio-frequency fields
150kHz to 80 MHz, 10 V
rms
IEC 61000-4-8 Power frequency magnetic field immunity
test
50/60 Hz, 100 A/m
100 A/m, 1 sec
IEEE C37.90.1 Temperature Testing: Operational Test
IEEE C37.90.1 Temperature Testing: Non-operational
Test
IEC 61000-4-16 Test for immunity to conducted, common
mode disturbances in the frequency
range 0 Hz to 150 kHz
DC - 150 kHz CM 3/30 V
rms
IEC 61000-4-17 Ripple on DC input power port immunity
test
15%
IEC 61000-4-18
IEEE C37.90.1 SWC
Ring wave immunity test ±2.5 kV CM/TM
Damped oscillatory wave immunity test
IEC 61000-4-29 Voltage dips, short interruptions and
voltage variations on DC input power port
immunity test
30/60/100% @ 24 VDC
Standard Name Description Test Specification
IEC 61010-1 Safety requirements for electrical
equipment for measurement, control and
laboratory use - General requirements
IEC 60255-5 Insulation coordination for measuring
relays and protection equipment-
Requirements and tests
Insulation Resistance >100 M Ω
Insulation Dielectric 0.7/2.8 kVDC
Insulation Impulse 1/5 kV
pk
Standard Name Description Test Specification
IEC 60068-2-1 Cold 2 hours non powered, soak at −40
°C, then warm to −20 °C and leave
powered for 16 hours
IEC 60068-2-2 Dry Heat 16 hours powered at +70 °C
IEC 60068-2-6
IEC 60255-21-1
Vibration (sinusoidal) A logarithmic sweep from 10 Hz to
150 Hz to 10 Hz at 1 oct/min for 1
sweep cycle in the 3 orthogonal
axes.
Acceleration level 1 g
IEC 60068-2-27
IEC 60255-21-2
Shock - Operating Response Test
Shock - Non-Operating Withstand Test
Pulse shape: Half sine Pulse
duration: 11 mS
- Operating Response Test:
Acceleration level: 5 g's
- Non-Operating Withstand Test:
Acceleration level: 15 g's
3 pulses per polarity per axis for a
total of 18 pulses
Bump – Non operating test Pulse shape: Half sine Pulse
duration: 11 mS Acceleration level:
10 g's
1000 pulses per polarity per axis for
a total of 6000 pulses
IEC 60068-2-31 Drop and topple Dropping on each face Dropping on
each corner Toppling (or pushover)
For a total of 12 drops, 50 mm
IEC 60068-2-78 Humidity Testing 96 hours steady state humidity at
40 °C and 93% RH
Standard Name Description Test Specification
