D20E Ethernet I/O Module
Appendix A: Standards & Protection
Standards & Pr otection
Compliance standards
Compliance standards are listed for the following categories:
• Table 40: Emission standards on page 121
• Table 41: Immunity standards on page 121
• Table 42: Safety publications on page 122
• Table 43: Environmental standards on page 122
• Table 44: Communication standards on page 123
Table 40: Emission standards
1
To comply, all RS232 cables must be double shielded (that is, foil shield plus braid).
Table 41: Immunity standards
Standard Name Description Test Specification
EN55011 (CISPR 11)
1
ISM RF equipment – Electromagnetic
disturbance characteristics
Radiated Emissions 30 MHz to
1
GHz
Conducted Emissions 150 kHz to
30
MHz
Standard Name Description Test Specification
IEC 61000-4-2
IEC 60255-22-2
IEEE
®
C37.90.3
Electrostatic discharge (ESD) immunity
test
8 kV contact
15 kV air discharge
IEC 61000-4-3
IEC 60255-22-3
IEEE C37.90.2 (10 V/m)
Radiated, radio-frequency
electromagnetic field immunity test
80 MHz to 1.0 GHz, 10 V/m
1.4 GHz to 2.0 GHz, 3 V/m
2.0 GHz to 2.7 GHz, 1 V/m
IEC 61000-4-4
IEC 60255-22-4
IEEE C37.90.1
Electrical fast transient/burst immunity
test
±4.0 kV CM/TM
IEC 61000-4-5 Surge immunity test ±2.0 kV / 4.0 kV TM/CM
