46 GE INFORMATION D20E ETHERNET I/O MODULE INSTRUCTION MANUAL
CHAPTER 3: CONFIGURING THE D20E FIRMWARE
9. Click Next.
Result: The Publishers page appears.
Only one Publisher (either DNP or IEC61850) may be configured for the D20E. In
order to change the Publisher protocol, you must create a new blank project.
10. Select the check-box for the protocol you wish to add to the D20E (DAP IO):
–DNP 3.0
– IEC 61850
The D20E 61850 Provider must have GOOSE enabled. If there is no GOOSE
configured in the SCL model, DAPserver Studio will not import the model.
11. Click Next.
Result: The Summary page appears showing a configuration summary.
12. Click Finish.
