CHAPTER 3: CONFIGURING THE D20E FIRMWARE
D20E ETHERNET I/O MODULE INSTRUCTION MANUAL GE INFORMATION 67
H Limit Specify the value for the high-value limit.
H Name Specify the name of the high-value event.
HH Limit Specify the value for the highest-value limit.
HH Name Specify the name of the highest-value event.
Rate of
Change
Specify the threshold value against which the
calculated change of ratio value is compared.
Set the value to 0 in order to disable the alarm.
Note: The Rate of Change will only be applied once
the user has configured a Min and Max value for the
specific Analog Input(s), within the Calculation tab.
0
(disable)
Rate of
Change
Name
Specify a name for the Rate of Change Event.
If left empty, no Rate of Change Event is generated.
Control settings
Reference
Name
Specify a text string that combines the bay name,
group name, and provider name from the General
tab.
Lower
Control Point
Specify the digital output point associated with a
lower operation applied to the analog input.
A custom window allows for the association of an
analog input to a digital output on the same device.
This feature can be disabled by leaving this setting
value empty; any lower control applied to this analog
input subtracts one from the value of this analog
input.
Raise Control
Point
Specify the digital output point associated with a
raise operation applied to the analog input.
A custom window allows for association of an analog
input to a digital output on the same device. This
feature can be disabled by leaving this setting value
empty; any raise control applied to this analog input
adds one to the value of this analog input.
Providers - Protocol settings
Reference
Name
Specify a text string that combines the bay name,
group name, and provider name from the General
tab.
Value Name Specify the name of the data attribute that holds the
value (e.g., stVal, mag, etc.)
Quality
Name
Specify the name of the data attribute that holds the
quality.
Time Name Specify the name of the attribute that holds the time
stamp.
Value Index Read-only value for internal use.
Quality Index Read-only value for internal use.
Time index Read-only value for internal use.
Publisher settings
Reference
Name
Specify a text string that combines the bay name,
group name, and provider name from the General
tab.
Point
Description
Specify the point description of the mapped analog
input.
Setting Descriptions Range Default
