DIRECTION 5472001-1EN, REVISION 6OPTIMA CT680 SERIES AND OPTIMA CT670 INSTALLATION MANUAL

Page 42 Section 5.0 - Install the Gantry

8.) Remove the four (4) gantry shipping bolts, using a 1½" socket.

Figure 1-9 Gantry Shipping Bolts

Note: Bolt requires

a 1-½" socket

Note:

Leave this locking ring

off, so that the alignment

bar will fit into the

alignment hole.
