GE COMPANY
DIRECTION 5472001-1EN, REVISION 6OPTIMA CT680 SERIES AND OPTIMA CT670 INSTALLATION MANUAL
Chapter 1 - Position Subsystems Page 45
1 – Pos. Subsystems
Figure 1-12 Bubble Level Centering
4.) Adjust the distance between floor and gantry base at Anchor location #1 becomes
approximately 17.0 mm by turning four (4) adjusters equally.
(Be careful no more than 1 turn at a time.)
Correct - 100%
Bubble
Incorrect < 100%
Correct level is 100% of bubble within small circle
Incorrect level is less than 100% of bubble within small circle
To Next Page
