Format for Parameter Setting 0xC1h
Address
I/O Fault Table with Remote Fault Record
(0xC1) Output Format
High Byte
Low Byte
Address+37
Reference address
memory type
Long/Short Value
Address+38
Reference address offset
Address+39
Slot
Rack
Address+40
Remote Slot
Remote Rack
Address+41
Remote Sub-Slot
Remote Device ID
Address+42
Bus address
I/O bus number (block)
Address+43
point
Address+44
Fault action
Fault group
Address+45
Fault type
Fault category
Address+46
Fault extra data
Fault description
Address+47—
Address+56
Fault extra data
Address+57—
Address+60
(Time-stamp
in BCD
Format)
Minutes
Seconds
Day of month
Hour
Year
Month
Milliseconds
Address+61
Not used
Address+62
Start of next fault output parameter block
