4-3-3 System Features
4-3-3-1 Control Panel
Figure 4-5 Control Panel Tour
1. Loudspeaker position 7. Menu window flipswitch controls
2. Menu window digipot controls 8. Mode keys(digipot controls)
3. TGC Slider controls 9. Toggle switch controls
4. Trackball 10. Hard keys
5. Alphanumeric Keyboard 11. Trackbal buttons
6. Probeholders
1
2
3
4
9
7
5
10
11
6
8
