GE DRAFT VOLUSON™ P8 / VOLUSON™ P6
DIRECTION 5723243, R
EVISION 6 DRAFT (MAY 23, 2018) BASIC SERVICE MANUAL
Chapter 8 - Replacement Procedures 8-1
Chapter 8
Replacement Procedures
Section 8-1
Overview
8-1-1 Purpose of Chapter 8
This chapter contains replacement procedures for different modules and their subsystems.
!! NOTICE:
The Manpower, time and Tools indicated in the Sub-sections include all requirements from
Preparations to Installation Procedures.
!! WARNING:
No covers or panels should be removed from the system (high-voltage risk).
Service and repairs must only be performed by authorized personal.
Attempting do-it-yourself repairs invalidate warranty and are an infringement to regu-
lations and are inadmissible acc. to IEC 60601-1. Under the condition of regular
maintenance by authorized service personnel a lifetime of 7 years for the equipment
and 5 years for the probes may be expected.
The Waste of Electrical and Electronic Equipment (WEEE) must not be disposed as unsorted
municipal waste and must be collected separately.
Please contact the manufacturer or other authorized disposal company for information
concerning the decommission of your equipment.
Table 8-1 Chapter 8 Contents
Section Description Page Number
8-1
Overview
8-1
8-2
System Software - Installation/Upgrade Procedure
8-4
8-3
Software and Functional Checks after Installation/Upgrade Procedure
8-20
8-4
Image Settings Only - Loading Procedure
8-22
8-5
Full Backup (Full System Configuration) - Loading Procedure
8-22
8-6
Image Archive - Loading Procedure
8-22
8-7
Replacement or Activation of Options
8-23
8-8
Replacement of FRONT CABINET BEZEL ASSY BT16
8-25
8-9
Replacement of ASSY BEZEL FRONT DVD PLASTIC BT16
8-26
8-10
Replacement of FRONT PRINTER BEZEL ASSY BT16
8-27
8-11
Replacement of Cover Top Cabinet Plastic
8-28
8-12
Replacement of Front PEDESTAL COVER BT16
8-30
8-13
Replacement of TRAY PEDESTAL CABINET PLASTIC BT16
8-32
