GE Voluson P8 BT16 - 8-46-5 Installation Procedure

To Next Page

To Previous Page

GE RAFT VOLUSON™ P8 / VOLUSON™ P6

DIRECTION 5723243, R

EVISION 6 DRAFT (MAY 23, 2018) BASIC SERVICE MANUAL

8-146 Section 8-46 - Replacement of the T-DPI

3.) Remove T-DPI from the EMI SHIELD BRACKET.

8-46-5 Installation Procedure

1.) Install the new parts in the reverse order of removal.

2.) Perform: FRU8-37: Replacement of the T-DPI - Functional Tests..

Figure 8-207 Removing the EMI SHIELD BRACKET

Figure 8-208 Bottom of T-DPI
