GE Voluson P8 BT16 - 8-17-4 Installation procedure

To Next Page

To Previous Page

GE RAFT VOLUSON™ P8 / VOLUSON™ P6

DIRECTION 5723243, R

EVISION 6 DRAFT (MAY 23, 2018) BASIC SERVICE MANUAL

8-50 Section 8-17 - Replacement of Keyboard Assembly-TOP

8.) Unscrew 2 screws and pick up the sub keyboard. Refer to the figures below.

8-17-4 Installation procedure

Install a new part in the reverse order of removal procedure.

Figure 8-63 Picking up the sub keyboard
