GE DRAFT VOLUSON™ P8 / VOLUSON™ P6
DIRECTION 5723243, R
EVISION 6 DRAFT (MAY 23, 2018) BASIC SERVICE MANUAL
Chapter 9 - Renewal Parts 9-11
Table 9-6 Nest Box
Item Part Name
Part
Number Description Qty FRU BT13 BT14 BT15 BT16
401
T-DPI PWA
assy
5719539-2 Probe Interface Board Assy 1 1 N N N Y
402 DBM64 Assy
5573639-2 64ch Dachstein Beamformer Mla4 1 1 N N N Y
403 DCWD Piggy
6497597-2 Dachstein CWD Piggy 1 1 N N N Y
404
DRFM -2 FRU
SET
S5497712-
2
DRFM-2 Assy with FPGA Patch 1 1 N N N Y
405 HDD
5459671 2.5inch 500GB SATA HDD 1 1 Y Y Y Y
406 CBP Assy
5364094 CBP ASSY 1 1 Y Y Y Y
407 CSI Assy
5364095 CSI Assy 1 1 Y Y Y Y
408 DVD unit
5393433 DVD Drive 1 1 Y Y Y Y
409
AC Cable
Holder
5408086 AC CABLE HOLDER SET 1 1 Y Y Y Y
410
OPIO Cable
Assy
6020400 OPIO Cable Assy 1 1 Y Y Y Y
411
System Main
FAN
5669586 System Main FAN 1 1 N N N Y
412
Type 6 COM
Express with 8G
Memory
5721572 i3 SOM with 8G Memory 1 1 N N N Y
413
i3 Skylake with
8Gbyte RAM
7324556
i3 Skylake with 8Gbyte RAM
(Usable in the system which is SW Ext.7 or
later version)
11 N N N Y
414
DPS with
battery Assy
6004002-2 DPS with battery Assy 1 1 N N N Y
415 DPS Assy
6004001-2 DPS Assy 1 1 N N N Y
416 Battery pack
5450061 Battery pack 1 1 N Y Y Y
417
HDMI Cable for
Main Monitor
5717001 HDMI Cable for Main Monitor 1 1 N N N Y
418
MONITOR
POWER cable
5717002 MONITOR POWER cable 1 1 N N N Y
419
USB Cable for
Main Monitor
5717003 USB Cable for Main Monitor 1 1 N N N Y
420
peripheral Cable
Assy
5445881 Peripheral Cable Assy 1 1 Y Y Y Y
421
Power cable for
DVD and
Cellular Module
5611034 Power Cable for DVD and Cellular Module 1 1 N N Y Y
