gefran 1650 User Manual

80209C_MHW_850-1650-1850_01-2020_ENG_pag. 221
OPEN
CLOSE
MAX
SIGNAL
MIN
+
VP
+
1V
-
Ph L+
Mp N-
M
19
20
21
22
23
24
18
17
16
15
14
13
7
8
9
10
11
12
PWR
COM
OUT4
OUT3
OUT2
Power neutral
Open command (phase)
Close command (phase)
Position reverse potentiometer
Auxiliary input
for models with Auxiliary Input option = 2
NOTE:
To enable the valve position control,
set parameter FUnC=VALV.P for the auxiliary input
Valve connection diagram
for models 850V (or 850PV)-X-RR-R...
default OUT2 (OPEN), OUT3 (CLOSE)
VALVE CONNECTION
OPEN
CLOSE
MAX
SIGNAL
MIN
+
VP
+
1V
-
Ph L+
Mp N-
M
19
20
21
22
23
24
18
17
16
15
14
13
7
8
9
10
11
12
PWR
OUT3
OUT2
C
NO
C
NO
Power neutral
Open command (phase)
Close command (phase)
Position reverse potentiometer
Auxiliary input
for models with Auxiliary Input option = 2
NOTE:
To enable the valve position control,
set parameter FUnC=VALV.P for the auxiliary input
VALVE CONNECTION
Valve connection diagram for models 850V
(or 850PV)-X-RR-0... / 850V (or 850PV)-X-RR-D...
default OUT2 (OPEN), OUT3 (CLOSE)
