CONTROL FUNCTIONS
CONTROL
Type Single loop, double loop
Control PID, ON/OFF, single action heat or cool, double action heat/
cool
Control output Continuous or ON/OFF
Cycle time: constant or optimized (BF)
Control output for motorized
valves
OPEN/CLOSE for floating motorized valve or with feedback with
position control by potentiometer on Relay, Solid-state, Triac
outputs.
SETPOINT
PROGRAMMER
(Double programmer if
double loop)
Number of programs Max 16 (if double loop 8 + 8) (*)
Start / Stop / Reset / Skip via digital inputs and/or outputs from
logic operations
Output state: Run /Hold / Ready / End
Number of steps Max 192, each with own setpoint, ramp time and hold time (**)
Times settable in HH:MM or MM:SS
Max 4 consents, configurable for ramp and for hold
Max 4 events, configurable in ramp and in hold
MULTIPLE
SETPOINTS
Number of setpoints Max 4, selectable from digital input
Each setpoint change is subject to set ramp, different for up
and down ramp
LOGIC
OPERATIONS
1
Digital function blocks Max 32, with 4 input variables per block.
The result can act on the state of the controller, of the programmer
on alarms and outputs.
Each function contains a block type AND, OR with TIMER
OPERATIONS
MATHEMATICAL
1
Analog function blocks Max 8, with 2 input variables per block, with operators such as +
, - , × , : , average, square root, ...
The result may act on analog variables in input to PID loops (con-
trolled variable, setpoint) or analog outputs .
TIMER FUNCTION
Modes START / STOP (2 timer if double loop)
STABILIZATION (timer is on when PV enters a band set around
setpoint; at end of count you can activate an output, shut down
SW or change SP1/SP2)
FIRING (timed activation of control after power on)
ENERGY COUNTER
Calculation done on nominal line voltage and nominal load power or
on rms current measured on load via CT
DIAGNOSTIC
Short circuit or open circuit (LBA alarm)
Interrupted or partially interrupted load (HB alarm)
Short circuit of control output (SSR alarm)
RETENTIVE MEMORY
Type FRAM
Max. number of writes Number max: > 10
10
cycles
Retention: > 10 anni
(*) if in standard mode; if in “Simplified programmer” mode, Max 12 programs
(**) freely selectable in any program, if in standard mode; if in “Simplified programmer” mode, MAX 16 steps per program, in a set
order: Program 1 Step 1-16, Program 2 Step 17 – 32, and so on
