gefran 1650 User Manual

80209C_MHW_850-1650-1850_01-2020_ITA_pag. 272
GENERAL DATA
POWER SUPPLY
Operating voltage 100...240 VAC/VDC ±10%, 50/60 Hz
(20...27 VAC/VDC ±10%, 50/60 Hz)
Power dissipation 10 W max
Protections Overvoltage 300 V / 35 V
Connection Screw terminals and crimp connector, max. wire section 1 mm
2
CONNECTIONS
Serial configuration port Connector: microUSB
RS485
(option)
Baudrate: 1200, 2400, 4800, 9600, 19.200, 38.400, 57.600,
115.200 bit/s
Protocol: Modbus RTU
Insulation compared to main entrance
Screw terminals and crimp connector, max. wire section 2.5mm
2
Master Modbus Baudrate: 1200, 2400, 4800, 9600, 19.200, 38.400, 57.600,
115.200 bit/s
Protocol: Modbus RTU Master
Connector: RJ10
RTU Bridge Baudrate: 1200, 2400, 4800, 9600, 19.200, 38.400, 57.600,
115.200 bit/s
Protocol: Modbus RTU Master
Screw terminals and crimp connector, max. wire section 2.5mm
2
Ethernet Modbus TCP e
Webserver
(opzione)
Baudrate : 10/100BaseTX, 10/100Mbit/s
Protocol : Modbus TCP slave, integrated Webserver
Isolamento compared to other peripherals
RJ45 Standard connector
Inputs and outputs Screw terminals and crimp connector, max. wire section 2.5mm
2
AMBIENT
CONDITIONS
Use Indoor
Altitude 2000 m max
Operating temperature -10 ... +55 °C (as per IEC 68-2-14)
Storage temperature -20 ... +70 °C (as per IEC 68-2-14)
Relative humidity 20...85% RH non-condensing (as per IEC 68-2-3)
PROTECTION LEVEL
IP 65 on front panel (as per IEC 68-2-3)
ASSEMBLY
Positioning On panel, removable faceplate
Installation regulations Installation category: II
Pollution degree: 2
Isolation: double
DIMENSIONS
48 X 96 mm (1/8 DIN)
Depth: 80 mm
WEIGHT
0,24 kg
CE STANDARDS
EMC conformity
(electromagnetic compatibility)
Conforms to Directive 2014/30/EU norme EN 61326-1
Emissions in industrial environment classe A
LVD safety Conforms to Directive 2014/35/EU norme EN 61010-1
CERTIFICATIONS
Generals This Gefran controller, when subjected to the necessary cal-
ibration operations in the field, is suitable for use in Nadcap
applications for any class of oven, from 1 to 6, according to
specification AMS2750E, paragraph 3.3.1.
Europe CE, RoHS, REACH
USA, Canada UL, cUL
Russia EAC
1) Programming is done with the GF_eXpress configuration program.

gefran 1650 Specifications

General

Brand	gefran
Model	1650
Category	Temperature Controller
Language	English
