ADL300 • Functions description and parameters list 105
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.18 4560 SpdFbkLoss activity ENUM Disable 0 4 RW FVS
Drive behaviour in case of the Speed fbk loss alarm is displayed. This alarm indicates the loss of the encoder feedback
signals. Each type of encoder generates the Speed fbk loss alarm di󰀨erently (incremental signal error, absolute signal er-
ror, serial error).
0 Ignore
1 Warning
2 Disable
3 Stop
4 Fast stop
For absolute Endat encoders and absolute Hiperface encoders, after the alarm is generated, the encoder reset command
must be sent to the encoder: during this procedure the application veries whether the encoder is signalling an encoder
alarm condition to the drive and the alarm is acquired from this.
The causes of the Speed fbk loss alarm and the information acquired from the encoder are shown in the SpdFbkLoss
code parameter 2172.
Note! See menu 15.13 for further information.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.19 4562 SpdFbkLoss holdoff ms UINT16 200 0 10000 RW FVS
Setting of the delay between the signalling of the speed feedback loss alarm condition SpdFbkLoss and the enabling of
the alarm. If an alarm condition occurs, the drive will wait for the set time before enabling the alarm. If the alarm is removed
within the set time, the drive will not indicate any alarm condition.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.20 4564 SpdFbkLoss threshold rpm INT16 100 5 CALCI RW FV_
If using incremental digital encoders in single-ended mode, this parameter sets the limit above which the drive executes
the action set with parameter 4560 SpdFbkLoss activity.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.21 4570 Drive ovld activity ENUM Disable 0 4 ERW FVS
Setting of the behaviour of the drive in case of a drive overload alarm Drive ovld. This alarm indicates that the drive over-
load threshold has been reached.
0 Ignore
1 Warning
2 Disable
3 Stop
4 Fast stop
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.22 4572 Motor ovld activity ENUM Warning 0 4 ERW FVS
Setting of the behaviour of the drive in case of a motor overload alarm Motor ovld. This alarm indicates that the motor
overload threshold has been reached.
0 Ignore
1 Warning
2 Disable
3 Stop
4 Fast stop
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.23 4574 Bres ovld activity ENUM Disable 0 4 ERW FVS
Setting of the behaviour of the drive in case of a braking resistor overload alarm Bres ovld. This alarm indicates that the
braking resistor overload threshold has been reached.
0 Ignore
1 Warning
2 Disable
3 Stop
4 Fast stop
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.24 4582 HTsens restart ENUM Disable 0 1 ERW FVS
