114 ADL300 • Functions description and parameters list
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
- 3214 Motor overload trip BIT 16BIT 0 0 1 ER FVS
This signal is active when the drive is in the motor overload alarm condition.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
- 3262 Bres overload trip BIT 16BIT 0 0 1 ER FVS
This signal is active when the drive is in the braking resistor overload alarm condition.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
- 3422 Direction change mon BIT 16BIT 0 0 1 ER FVS
This signal stays on for one second each time the drive detects a direction change and thus decrements the counter.
This signal is inserted in the L_DIGSEL1 selection list and can be brought to a digital output.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
- 3424 Dir change cnt zero BIT 16BIT 0 0 1 ER FVS
This signal activates when the drive is locked because 3414 Direction counter has reached 0.
This signal is inserted in the L_DIGSEL1 selection list and can be brought to a digital output.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
- 4708 Alm dig out mon 1 BIT 16BIT 0 0 1 ER FVS
This signal is activated when the alarm congured in parameter 4700 alarm dig sel 1 is active.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
- 4710 Alm dig out mon 2 BIT 16BIT 0 0 1 ER FVS
This signal is activated when the alarm congured in parameter 4702 alarm dig sel 2 is active.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
- 4712 Alm dig out mon 3 BIT 16BIT 0 0 1 ER FVS
This signal is activated when the alarm congured in parameter 4704 alarm dig sel 3 is active.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
- 4714 Alm dig out mon 4 BIT 16BIT 0 0 1 ER FVS
This signal is activated when the alarm congured in parameter 4706 alarm dig sel 4 is active.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
- 4770 First alarm UINT32 16BIT 0 0 0 ERW FVS
This parameter displays the rst alarm to be activated..
0 No alarm
1 Overvoltage
2 Undervoltage
3 Ground fault
4 Overcurrent
5 Desaturation
6 MultiUndervolt
7 MultiOvercurr
8 MultiDesat
9 Heatsink OT
10 HeatsinkS OTUT
11 Intakeair OT
12 Motor OT
13 Drive overload
14 Motor overload
15 Bres overload
16 Phaseloss
17 Opt Bus fault
18 Opt 1 IO fault
19 Opt 2 IO fault
20 Opt Enc fault
