Generic Onyx 50 User Manual

- 154 -
Clean grease on the driven wheel surface.
Install oil seal of driven left semi slide bushing.
Install greased O shape ring in driven left semi part.
润滑油脂 Lubricating grease
油封 Oil seal
O 型圈 O shape ring
Assemble left and right parts of driven wheel together.
Install greased directing pin into directing groove.
Install spring bushing. 。
Clean leaked grease.
弹簧护套 spring bushing
扳手 spanner (locking nut)
离合器弹簧压缩器 clutch spring compressor
D
efined grease
B
all bearing
B
earing driver
N
eedle bearing
