34
Note: Total fps is displayed as SUM/MAX. MAX for NTSC is 480 and for
PAL 400. If the sum of fps is over the MAX fps a warning message pops
up. Then the last channel is automatically disabled.
3.3. Continuous /Normal Recording
The DVR comes with certain preset settings from the factory. Therefore once
the DVR is installed immediate recording is possible after pressing the REC
button. By default, audio, alarm, motion recording are off.
The DVR records video data continuously over a 24 hour period. Recording
setup is for normal recording. Different settings can be configured for each
camera. To copy the setting to another channel, press the Display button.
ITEM
ADJUSTMENT
RES. y Display selected resolution in MODE tab.
AUDIO y Select to record audio.
F/S y Frames per second: Select recording speed rate for each camera.
QUALITY
y Specify the recording picture quality for each camera.
ULTRA Æ SUPER Æ HIGH Æ MIDDLE ÆLOW
