GW Security GW78 - 1.2 Rear Panel

1.2 Rear Panel
NVR Rear Panel, as shown in figure 1-8 to figure 1-12.
Figure 1-8 Rear panel of MX8 case
Figure 1-9 Rear panel of NX3 case
1
2
3
4
5
6
7
9
8
10
11
Figure 1-10 Rear panel of WX1 case
No.
Description
1
Power Input Interface
2
Power switch
3
Exhaust Fan Vent
4
Alarm in/out Interface
5
Audio in/out Interface
6
VGA interface
7
HDMI interface
8
eSATA Interface
9
RJ45 interface
10
USB 3.0 interface
11
Caution Information Sticker
Table 1-3 Description of Rear Panel
Note:
 All above drawings are for reference only.
