User Manual
Page 11
RS-485
For connection to PTZ cameras.
ALARM OUT
For Relay output.
1
ALARM IN
1~16 channel alarm input
2
VGA
Connection to a VGA monitor or TFT LCD.
3
RS232 PORT
Connection to PC or other DVR control devices.
4
ETHERNET
The RJ-45 port is used to connect the DVR to a network
5
MOUSE
For PS/2 mouse.
AUDIO IN
1~4 channel audio input
AUDIO OUT
Connect to audio output device such as a speaker.
6
MIC IN
Connect to microphone for two way audio.
7
1~16 CAMERA
IN/LOOP OUT
Channel 1~16 camera input and loop out.
8
MONITOR OUT
Main monitor output.
9
SPOT
Second monitor output. Once alarm or motion is triggered, it will pop up
automatically or display in sequence according to the set up.
10
Power Switch
Power ON/OFF
11
POWER
Connect Power adaptor
