User Manual
Page 12
CAUTION! Electrostatic discharges (ESD)
Any electrostatic charge in contact with hard disk drives or other electronic components in the DVR
unit will cause damage permanently. Improper handling could void the warranty of the hard disk.
When working with electrostatic sensitive devices such as a hard disk drive or the DVR unit, make sure you
perform installation from static free workstation.
z Mounting Instructions
z Remove Top Cover
Locate the hard drive mounting bracket and install as shown below example in Figure.
CHAPTER 2. HARDWARE CONFIGURATION
3. Hard Disk Drive
HDD1
HDD2
HDD2
To Next Page
