H.264 4CH - 7-3.Video Loss

User Manual
Page  49
[2]ACTION
Set Alarm-Out On / Off for each channel in case motion is detected.
NO Click the“Number＂button to show the“COPY SETTINGS＂popup menu.
ALARM-OUT
Set “ON” or “OFF” for sending alarm signal to relay output terminal.
※16 channel DVR has 1 and 2 out ports
DURATION Set alarm dwell time from 1 to 99 seconds.
EVENT REFRESH TIME Set interval from 1 to 99.
Setup configuration for video loss by each camera
NO Click the“Number＂button to show the“COPY SETTINGS＂popup menu.
BEEP Beep “ON” or “OFF” for audible Video loss indication
ALARM-OUT
Set “ON” or “OFF” for sending alarm signal to relay output terminal.
※16 channel DVR has 1 and 2 out ports
DURATION Set alarm dwell time from 1 to 99 seconds.
EVENT REFRESH TIME Set interval from 1 to 99.
CHAPTER 7. EVENT
3.VIDEO LOSS
