H.264 4CH - Specification

User Manual
Page  5
MODEL 4CH 8 CH 16 CH
VIDEO IN / OUT
Video Inputs 4 BINC 8 BNC 16 BNC
1 BNC, 1 VGA, 1 Spot(Analog)
Video Outputs
4CH Loop outs 8 Loop outs 16 Loop outs
Audio Input 1 ch 2 ch 4 ch
Audio Output 1 ch 1 ch 1 ch
Alarm Input 4 8 16
Alarm Output 1 Relay out 2 Relay Out
704×480(704x576) 120(100)fps 120(100)fps 120(100)fps
704×240(704x288) 120(100)fps 240(200)fps 240(200)fps
Recording Speed (NTSC/PAL)
352×240(352x288) 120(100)fps 240(200)fps 480(400)fps
Recording Mode
Schedule (Time, Motion, Alarm, T+M, T+A),
Holiday, Panic, Pre-Event
Search mode Date/Time, Event, Calendar, Bookmark
Multi Channel Playback Available
Display Mode 1, 4, 6, 8, 9, 13, 16, PIP, SEQ
Zoom Digital Zoom x2
Motion detection area Detection Division: 32x32
Multi-tasking Quadplex (Live, Playback, Recording, Network)
Event Log Available
Remote Software Integrated Remote Station (Monitoring, Search & Playback, Back-up)
Internal Explorer Support Available
Simultaneous remote user access 4 persons
RS232 / RS485 Port 1 / 1 ea
Network Port 10/100 Ethernet
USB Port USB 2.0 (1ea)
IR Remote Control port Yes
Primary Storage SATA HDD (2ea)
DVD RW SATA DVD writer (1ea)
Data Export Medium USB (HDD, FlashDrive), DVD-RW
Operation PS2 Mouse / Remote Controller / Front Panel Buttons
Specification
